CÓDIGO | POTENCIA | FLUJO de PLACA | HUECO INDIVIDUAL | HUECO LÍNEA CONTINUA (LC) | LARGO FRENTE (LF) | ANCHO FRENTE |
---|---|---|---|---|---|---|
IMI056 | 13 w | 2200 lm | 40x569mm | 40x564mm | 585 mm | 50 mm |
IMI085 | 19 w | 3300 lm | 40x850mm | 40x845mm | 866mm | 50 mm |
IMI113 | 26 w | 4400 lm | 40x1135mm | 40x1126mm | 1147mm | 50 mm |
IMI141 | 32 w | 5500lm | 40x1415mm | 40x1407mm | 1428mm | 50 mm |
IMI169 | 38 w | 6600 lm | 40x1695mm | 40X1689mm | 1710mm | 50 mm |
IMI226 | 52 w | 8800lm | 40x2260mm | 40x2250mm | 2271mm | 50 mm |
IMI282 | 65 w | 11000lm | 40x2825mm | 40x2815mm | 2836mm | 50 mm |
